QSFP28 · QSFP+ · SFP28 · SR4 · LR4 · CWDM4 · DAC · AOC
100G, 40G and 25G optics — QSFP28, QSFP+ and SFP28, coded for your switches
Send the part numbers and quantities you need. We quote today’s landed price on 100GBASE-SR4, LR4 and CWDM4, 40G SR4 and LR4, 25G SR and CSR modules, and 100G DAC and AOC assemblies — Cisco, Juniper, Arista, HPE, Mellanox and Huawei coding, QC-tested and shipped from our Shenzhen facility.
- Coded to boot clean on NX-OS, IOS-XE, JunOS, EOS, Onyx and Cumulus — no “unsupported transceiver” lockout.
- DDM/DOM on every module; MPO-12 for SR4, duplex LC for LR4 and CWDM4.
- Original and OEM side by side — you pick per line.
20
coded part numbers on this page — or send your own
48 h
typical quote turnaround, UAE business time
3–7 days
Shenzhen → Dubai, air DDP, customs handled
1 year
hardwaresys warranty on every unit
Build your request
- 1Part numbersParts
- 2Your detailsDetails
- 3SentSent
Tap what you need — all of these are coded and quotable today. Mixing vendors and conditions in one request is fine.
Not in the list?
We quote well beyond this list — add a line and type the part number, or paste the BOM you’re working from.
Paste a list (BOM)
One line per item. Part number first, then quantity and condition if you have them — commas, tabs or spaces all work.
Your request
nothing selected yetNothing selected yet — tap a part above, or add your own part number.
Why we don’t publish a price
Optics pricing moves with the market daily, so a static number would be wrong by tomorrow. Send the part numbers and quantities — you get today’s real number.
Landed cost
Duty and delivery already in it, not a factory-gate figure.
The rate for the day you buy
Not last quarter’s — we re-check the market before every quote.
A number per condition
Quoted side by side, so you compare on one sheet.
What you’re buying
You pick this per line in the request, so it’s worth two minutes. The warranty is the same either way.
Original
- What it is
- Vendor-boxed, sealed, with the vendor’s own serial and packaging.
- Warranty
- 1-year hardwaresys warranty, on top of whatever the vendor carries.
- Pick it when
- Spine and core links under vendor support, or where procurement policy names the vendor part.
OEM
- What it is
- Produced on the same line as the vendor part, supplied in bulk or open-box rather than retail packaging.
- Warranty
- 1-year hardwaresys warranty.
- Pick it when
- Same silicon and same coding, at a lower landed cost than retail boxes.
Checked, boxed — then it ships.
Modules are coded and checked against the platform you name before they are boxed.
Coding & compatibility
Every module is coded to the platform you name, so it links up and reports DDM exactly like the vendor part — no “unsupported transceiver” message in the log.
- Cisco NexusNX-OS · 9300 · 9500
- Cisco CatalystIOS-XE · 9500 · 9600
- JuniperJunOS · QFX5120
- Huawei CloudEngineVRP · 6800 · 8800
- NVIDIA / MellanoxOnyx · Cumulus · Spectrum
- AristaEOS
- HPE / ArubaAOS-CX · Comware
Tell us the switch model in your request and we code the modules to it before they ship. Platform not on this list? Message us and we’ll check it →
switch# show interface Ethernet1/49 transceiver details
Ethernet1/49
transceiver is present
type is QSFP-100G-SR4
name is CISCO-INNOLIGHT
part number is TR-FC85S-NC3
revision is 2C
nominal bitrate is 25500 MBit/sec per channel
Lane Temperature Voltage Tx Power Rx Power
(Celsius) (Volts) (dBm) (dBm)
---- ----------- -------- -------- --------
1 41.20 3.28 -1.12 -1.87
2 41.20 3.28 -1.04 -1.93
3 41.20 3.28 -1.19 -2.05
4 41.20 3.28 -1.08 -1.78
switch# show interface Ethernet1/49 status
Port Name Status Vlan Duplex Speed Type
Eth1/49 connected trunk full 100G QSFP-100G-SR4Send your part numbers — we check them first
Paste the list you are working from. We verify each part against the platform it has to sit in and against the workload it has to carry, and we tell you where the configuration is wrong before it becomes an order. On one energy-sector project that recalculation took 25% out of the customer’s hardware spend.
How far each one reaches
- SR4 / SR
- up to 100 m · 850 nm · MMF
- CWDM4
- up to 2 km · 1310 nm · SMF
- LR4 / LR
- up to 10 km · 1310 nm · SMF
- ER4
- up to 40 km · 1310 nm · SMF
- SR4 / SR — OM4 · MPO-12 · in-row leaf-to-spine
- CWDM4 — duplex LC · between halls
- LR4 / LR — duplex LC · campus and metro
- ER4 — available to order
How it works
Pick your parts
You: Click the part numbers above or type your own — mix vendors and conditions in one list.
We: We read it as one request, not five.
Send the request
You: Add quantities and your email. No account, no obligation.
We: We check coding against your platform before quoting. Answers come by email or WhatsApp — whichever you used — from one manager, not a chat thread with five suppliers.
Get today’s price
You: Nothing — check your inbox.
We: We reply within 48 hours with a firm, landed quote for the current market.
Warranty & delivery
Warranty — 1 year from hardwaresys
Every module, original or OEM, carries a one-year Return-to-Base warranty.
Shenzhen → Dubai, DDP
Ready in Shenzhen — modules ship air, door-to-door with customs handled. Coded-to-order batches are build to order (BTO).
Before it ships to you
Every unit is switched on first.
The bench where a card gets powered and pinged, and the line that builds boards like it.
Frequently asked questions
Yes. Each module is coded to the platform you tell us — Cisco NX-OS/IOS-XE, Juniper JunOS, Arista EOS, Mellanox Onyx or Cumulus, Huawei VRP. It links up and reports per-lane DDM exactly like the vendor part. Tell us the switch model on the request and we match the coding.
SR4 runs to 100m over OM4 multimode on an MPO-12 trunk and is the normal leaf-to-spine choice inside a row. CWDM4 reaches 2km and LR4 10km, both over duplex single-mode LC — those are for links between halls, buildings or sites. If you are unsure, send us the distance and the fibre you already have and we will tell you which one fits.
Yes. QSFP28, QSFP+ and SFP28 go in one list with quantity and condition per line, and we return a single quote covering all of them. DAC and AOC assemblies can go on the same sheet.
Yes. Passive copper (DAC) and active optical (AOC) assemblies are on the list above, and breakout comes as DAC or AOC too. Tell us the ports on both ends and the length, and we quote the assembly rather than leaving you to match two half-solutions.
Yes. Huawei modules are quoted under the Huawei model and BOM code (QSFP28-100G-SR4 · 02311GBW, QSFP28-100G-LR4 · 02311KNU), NVIDIA/Mellanox under the MMA and MCP codes. If you only have a description, send that and we will name the part back to you before quoting.
Send the part numbers and quantities and you’ll have today’s landed price, usually within 48 hours, UAE business time. Modules ready in Shenzhen ship from there; air to Dubai is typically 3–7 days DDP. Coded-to-order batches are build to order (BTO).
Ready? Build your request
Send the part numbers and quantities — we’ll come back with today’s landed price within 48 hours. No account, and no price shown until we confirm the rate.
