1G SFP · SX · LX/LH · ZX · BiDi · 1000BASE-T
1G SFP transceivers — SX, LX/LH, BiDi and copper, coded for your switches
Send the part numbers and quantities you need. We quote today’s landed price on 1000BASE-SX, LX/LH, ZX, BiDi and copper SFP modules — Cisco, HPE Aruba and Juniper coding, QC-tested and shipped from our Shenzhen warehouse.
- Coded to boot clean on IOS-XE, JunOS and ProCurve — no “unsupported transceiver” lockout.
- DDM/DOM on every optical module; SX 850nm to 550m, LX/LH 1310nm to 10km, ZX 1550nm to 70km.
- Original and OEM side by side — you pick per line.
20
coded part numbers on this page — or send your own
48 h
typical quote turnaround, UAE business time
3–7 days
Shenzhen → Dubai, air DDP, customs handled
1 year
hardwaresys warranty on every unit
Build your request
- 1Part numbersParts
- 2Your detailsDetails
- 3SentSent
Tap what you need — all of these are coded and quotable today. Mixing vendors and conditions in one request is fine.
Not in the list?
We quote well beyond this list — add a line and type the part number, or paste the BOM you’re working from.
Paste a list (BOM)
One line per item. Part number first, then quantity and condition if you have them — commas, tabs or spaces all work.
Your request
nothing selected yetNothing selected yet — tap a part above, or add your own part number.
Why we don’t publish a price
Optics pricing moves with the market daily, so a static number would be wrong by tomorrow. Send the part numbers and quantities — you get today’s real number.
Landed cost
Duty and delivery already in it, not a factory-gate figure.
The rate for the day you buy
Not last quarter’s — we re-check the market before every quote.
A number per condition
Quoted side by side, so you compare on one sheet.
What you’re buying
You pick this per line in the request, so it’s worth two minutes. The warranty is the same either way.
Original
- What it is
- Vendor-boxed, sealed, with the vendor’s own serial and packaging.
- Warranty
- 1-year hardwaresys warranty, on top of whatever the vendor carries.
- Pick it when
- Links inside an estate that stays under vendor support.
OEM
- What it is
- Vendor-produced modules supplied in bulk rather than retail packaging — the same optic without the retail carton.
- Warranty
- 1-year hardwaresys warranty.
- Pick it when
- Same part, lower landed cost, when the box itself is not the point.
Checked, boxed — then it ships.
Modules are coded and checked against the platform you name before they are boxed.
Coding & compatibility
Every module is coded to the platform you name, so it links up and reports DDM exactly like the vendor part — no “unsupported transceiver” message in the log.
- CiscoIOS-XE · IOS
- JuniperJunOS
- HPE ArubaArubaOS-Switch (ProCurve)
Tell us the switch model in your request and we code the modules to it before they ship. Platform not on this list? Message us and we’ll check it →
Switch#show interfaces GigabitEthernet1/0/25 transceiver
ITU Channel not available (Wavelength not available),
Transceiver is internally calibrated.
Port Temperature Voltage Current Optical TX Optical RX
(C) (V) (mA) (dBm) (dBm)
Gi1/0/25 31.2 3.28 17.4 -5.1 -7.3
Port Name Vendor PN Vendor SN
Gi1/0/25 1000BaseLX SFP GLC-LH-SMD •••••••••••Send your part numbers — we check them first
Paste the list you are working from. We verify each part against the platform it has to sit in and against the workload it has to carry, and we tell you where the configuration is wrong before it becomes an order. On one energy-sector project that recalculation took 25% out of the customer’s hardware spend.
How far each one reaches
- 1000BASE-SX
- up to 550 m · 850 nm · MMF
- 1000BASE-LX/LH
- up to 10 km · 1310 nm · SMF
- 1000BASE-BX10
- up to 10 km · 1490 nm · SMF
- 1000BASE-ZX
- up to 70 km · 1550 nm · SMF
- 1000BASE-SX — OM2 multimode
- 1000BASE-LX/LH — MMF only with a mode-conditioning cord
- 1000BASE-BX10 — single fibre, D and U ordered as a pair
How it works
Pick your parts
You: Click the part numbers above or type your own — mix vendors and conditions in one list.
We: We read it as one request, not five.
Send the request
You: Add quantities and your email. No account, no obligation.
We: We check coding against your platform before quoting. Answers come by email or WhatsApp — whichever you used — from one manager, not a chat thread with five suppliers.
Get today’s price
You: Nothing — check your inbox.
We: We reply within 48 hours with a firm, landed quote for the current market.
Warranty & delivery
Warranty — 1 year from hardwaresys
Every module, original or OEM, carries a one-year Return-to-Base warranty.
Shenzhen → Dubai, DDP
Ready in Shenzhen — modules ship air, door-to-door with customs handled. Coded-to-order batches are build to order (BTO).
Before it ships to you
Every unit is switched on first.
The bench where a card gets powered and pinged, and the line that builds boards like it.
Frequently asked questions
Original is vendor-boxed and sealed, with the vendor’s own serial. OEM is the same vendor-produced module supplied in bulk rather than in a retail carton. Both are coded for your platform, both carry the same 1-year hardwaresys warranty. If your policy allows compatible-coded optics, say so in the request — we quote them separately.
GLC-T and SFP-GE-T reached end of sale on 1 June 2017; Cisco’s own replacement is GLC-TE, which is what we quote. If you need GLC-T for an estate that will not take the newer code, say so — that comes as refurbished stock, not as new.
Two, and they must be a pair. GLC-BX-D transmits at 1490nm and receives at 1310nm; GLC-BX-U is the mirror. One at each end of a single fibre. Ordering four of the same code leaves you with a link that will not come up.
Only with a mode-conditioning patch cord, and then to 550m. Over single-mode it goes to 10km without one. Tell us the fibre you have and we will say which module and cord the link needs.
Send the part numbers and quantities and you’ll have today’s landed price, usually within 48 hours, UAE business time. Modules ready in Shenzhen ship from there; air to Dubai is typically 3–7 days DDP.
Ready? Build your request
Send the part numbers and quantities — we’ll come back with today’s landed price within 48 hours. No account, and no price shown until we confirm the rate.
